Audio Technica VM750SH Dual Moving Magnet Stereo Cartridge with Shibata stylus
Zoom  Zoom

Audio Technica VM750SH Dual Moving Magnet Stereo Cartridge with Shibata stylus

  (5 Reviews)
£369.98
£308.32 Exc. VAT |  |
Share

Audio Technica VM750SH Dual MM Stereo Cartridge

VM750SH

Fitted with the Shibata stylus, which was developed for playing 4 channel vinyl records that demand high-frequency reproduction capabilities during playback. Not only for high-frequencies, it is also ideal for reproducing rich mid- and low-frequencies.

DUAL MOVING MAGNET STEREO CARTRIDGE

Using an ultra-lightweight stylus tip ground to a high level of precision, we have achieved a combination of low distortion rate with fuller frequency reproduction during playback. This stylus tip extracts every possible piece of information from the grooves on a record.

AUDIO-TECHNICA’S INTERNATIONALLY-PATENTED DUAL MAGNET DESIGN REPLICATES THE STRUCTURE OF THE CUTTER HEAD.

Instead of using a single, large magnet, the two magnets are arranged in the shape of a "V". The two magnets are positioned precisely to match the positions of the left and right channels in the stereo groove walls. Consequently, the VM design ensures outstanding channel separation, extended frequency response and superb tracking.

Para-toroidal generating system

Para-toroidal coils improve generating efficiency and offers superb linearity, since leakage of magnetic flux in this continuous and unitised magnetic circuit is low. Permeability of the cores is also optimised through the use of laminated cores.

Centre shield plate reduces crosstalk

A permalloy centre shield plate enables the effective separation of left and right channels, suppressing electrical crosstalk to below 40dB. This is similar to the actual crosstalk value found in the grooves of the record itself.

Features:

  • Beautiful mid-high range Shibata-signature sound and strong mid-range volume
  • VM type dual magnet design ensures outstanding channel separation, extended frequency response and superb tracking
  • Lightweight tapered aluminium cantilever allows for faithful reading of the record groove
  • Centre shield plate enables the effective separation of left and right channels, suppressing electrical crosstalk to below 40dB
  • Die-cast aluminium alloy housing reduces vibration and adds a natural electrical shield.
Type VM Type
Mounting 1/2” centres
Frequency Response 20 - 27,000Hz
Channel Separation 30dB (1kHz)
Output Channel Balance 1.0dB (1kHz)
Output Voltage 4.0mV (1kHz, 5cm/sec.)
Vertical Tracking Angle 23˚
Vertical Tracking Force Range 1.8 – 2.2g (2.0g standard)
Stylus Shape Shibata
Stylus Size 0.26 x 2.7 mil
Stylus Construction Nude Square Shank
Cantilever Aluminium Tapered Pipe
Coil Impedance 2,700Ω (1kHz)
Static Compliance 40 x 10-6 cm/dyne
Dynamic Compliance 10 x 10-6 cm/dyne (100Hz)
Recommended Load Impedance 47,000Ω
Recommended Load Capacitance 100 – 200pF
Weight 8.0g
Dimensions 17.3 (H) x 17.0 (W) x 28.2 (L) mm
Replacement Stylus VMN50SH
Accessories Included Cartridge installation screws 5mm ×2 and 10mm ×2, Washer ×2, Hexagon nut ×2, Non-magnetic screwdriver ×1, Brush ×1, Lead wire set ×1
Average Rating (5 Reviews):
Write a Review and share your opinions!
Rating:
Last cart
20 April 2022  |

Best MM cart I've ever owned.A very musical experience.

Was this helpful to you?  Yes  /  No

3 of 5 people found this review helpful.

Rating:
Stunning
17 January 2022  |

This cartridge has totally put my faith back into vinyl.

One of the most sweetest sounding cartridges I’ve heard since the early 80’s and the only one that I honestly can say comes close to hearing that classic years of vinyl in my opinion.
It actually reminded me quite a bit of the Technics EPS-205mk3 & my 4’s which in the day were utterly stunning pick up cartridges.
I’ve been using for the last 10 years the Clearaudio Maestro which although very X-Ray and clinical and also very musical doesn’t have this sweetness to it. I’d go as far as saying it’s actually better then the Clearaudio.

A beautiful pick up cartridge, so happy I made the choice.

Amazing quick delivery from Analogue Seduction too. Brilliant.

Was this helpful to you?  Yes  /  No

10 of 10 people found this review helpful.

Rating:
Audio Technica VM750 SH Cartridge
05 December 2021  |

Excellent tetephone order service .
Competitive price .
Excellent product knowledge .
Order completed & delivered promptly.

Was this helpful to you?  Yes  /  No

1 of 5 people found this review helpful.

Rating:
Much better than expected
17 June 2021  |

I installed the cartridge after removing my 95ML. I really enjoyed my Audio Technica AT-VM95ML and I was not sure the VM750SH would be much better, maybe just nuances. Even from the first groove I was astonished. The first thing I noticed was the bass. Deeper and better defined. My second thought was that the highs were a bit harsh. After just a couple of hours of listening it settled down. The amount of detail that the cartridge can pull out of the groove is amazing. I have heard things that I have never heard before. This is on albums that I have known for over 50 years. A third area of excellence is the soundstage. It is higher and wider than previously. I was reading and listening and looked up because I heard a tambourine that was 1 foot above and 2 feet outside the left speaker. Just amazing. If you have the turntable, phonostage, amplifier and speakers to do this cartridge justice. Just go for it. You won't be disappointed.

Was this helpful to you?  Yes  /  No

6 of 6 people found this review helpful.

Rating:
AT VM750SH
25 August 2019  |

Product easy to fit thanks to the removable stylus. Early impressions are superb, excellent clarity, separation and sound stage. Only occasionally does it sound to bright. Most surprising trait of all though, is its ability to not detect as much surface noise from the groove, I assume this is down to the size and shape of the Shibata stylus. All in all a more enjoyable listen than my previous cartridge(Micro Benz MC Gold) and definitely worth the expense.

Also the usual, exceptional service was given by Analogue Seduction. Order placed and received within two days

Was this helpful to you?  Yes  /  No

14 of 14 people found this review helpful.
