Sky Analog  P-1 Cartridge
Zoom  Zoom
Sky Analog  P-1 CartridgeSky Analog  P-1 CartridgeSky Analog  P-1 CartridgeSky Analog  P-1 Cartridge

Sky Analog P-1 Cartridge

£475.00
£395.83 Exc. VAT |


|

Sky Analog P-1 Cartridge

SkyAnalog initially started designing tube amplifiers, much later they started designing High-End MC pickups. The G-series has, among other things, a unique aluminum body and a cantilever of Boron.



MODEL P-1 SPECIFICATIONS

PHYSICAL
Cantilever Boron
Stylus Diamond
Stylus Tip Radius 5 x 150 µm
VTA Vertical Tracking Angle 20˚
Coil Pure Iron Cross Coil
Weight 8.9 grams
ELECTRICAL
Output Voltage 0.35 mV @ 3.54 cm/s
Internal Impedance 6 Ω
Frequency Respons 20 – 20.000 Hz +/- 1 dB
Channel Separation ˃ 30 dB at 1 kHz
Channel Balance < 0.5 dB
DYNAMIC
Tracking Ability @ 315 Hz / 2 grams 80 µm
Dynamic Compliance 12 µm / mN
SETUP INSTRUCTION
Recommended Load 100 – 220 Ω
Recommended Tracking Force 1.6 – 2.0 grams
Optimum Tracking Force 1.8 grams
Recommended Tonearm Mass Medium
Optimum Working Temperature 23 ˚C
Break-In Period 30 hours

Be the first to Write a Review for this item!
