Conductor Material: | HYBRID: High purity dense Silver coated high purity Matched Crystal OFC + Linear Structured Carbon ® saturated layer(s) |
Design Purpose/ Application Area(s): | Loudspeaker cable |
Eff. Conductor Ø/Eq. AWG No./Strands: | 2x(2.96 mm² / AWG 12.5 / 147) |
External Diameter / -Dimensions: | 16.5 mm. wide; 6.0 mm. thick |
Resistance 20 °C / 68 °F: | 0.58 Ohm/100 m. |
Insulation / Dielectric Strength / Test Voltage: | HULLIFLEX ® 3 / 300 Vrms min. |
