The Power Supply unit is crucial to guarantee the best performances and Pianosa features electronic controls for 33/45rpm mode and for speed fine adjustments, any adjustment is saved and stored in memory even when unplugged from the AC.
Thanks to our proprietary power control generator based on a Quadral-Core micro-controller, Pianosa can effectively control vibrations and deliver high torque for the greatest dynamic and resolution.
The platter Spindle/Bearing system is made of the best hardened steel and bronze to grant superior precision, the platter is made of Poly-Vinyl (23mm thick) - rigid but dead at the same time - and the new polished hourglass pulley is shaped to improve the transmission:
every detail is designed to reduce vibrations, noise and wow&flutter with improved rotational stability.
EXTRA RIGID & DAMPENed
Pianosa is built with a multiple plinth structure, with a 50mm curved plinth in Italian Walnut hardwood slats and a lacquered MDF plinth for optimal structural stability. The curved wooden plinth is reinforced with a stainless steel board and the black lacquered MDF plinth to achieve the best vibrational control.
QUADRAL-CORE POWER SUPPLY
Pianosa features a proprietary power control generator based on Quadral-Core micro controller enhances an audio converter completely reshape the AC wave to perfectly drive a 12V synchronous motor to virtually cancel vibrations and improve torque power for greatest dynamic and details resolution both.
HIGH PRECISION PLATTER
Pianosa features our high precision platter bearing/spindle design with the best coupling tolerance available today: the rectified spindle is made of hardened chromed steel and the chromed ball bearing guarantee perfect rotational stability and low noise.
EASY SET UP
Ready to play out of the box, the set up includes a dedicated Gold Note B-5.1 tonearm and a custom moulded transparent polycarbonate Dust Cover easy removable with its new innovative detachable hinges.
Dimensions: 425mm W | 200mm H | 360mm D
Weight: 13,5Kg
Wow & Flutter: 0,1%
Rumble: -77dB
Speed: 33-1/3 and 45 rpm +/-0,1%
Speed changing: electronic with fine pitch control
Transmission: 70 shore rectified NBR belt
Motor: 12 Volt High Torque synchronous externally powered
Platter: 23mm Dampened Poly-Vinyl
Platter spindle: Split-Spindle™ clamping platter design
Platter bearing: Chromed steel 5mm ball bearing with adjustable brass seat
Dust Cover: Polycarbonate included
POWER
Mains supply: 100/115/230V, 50/60Hz
Power consumption: 20W max
LOWER PLINTH
Italian Walnut | Black Lacquered MDF
UPPER PLINTH
Black Lacquered MDF
METAL
Black anodised aluminium or optionally all Silver
PLATTER
Black Poly-Vinyl
