NuPrime Audio Omnia SW-8 Switch
Zoom  Zoom
NuPrime Audio Omnia SW-8 SwitchNuPrime Audio Omnia SW-8 SwitchNuPrime Audio Omnia SW-8 Switch

NuPrime Audio Omnia SW-8 Switch

£550.00
£458.33 Exc. VAT |


|

NuPrime Audio Omnia SW-8 Switch

The Omnia SW-8 is a high-end 8-port gigabit Ethernet Network Switch that improves the network performance by reducing signal noise. Errors in the network cause data packets to be resent and degrade network performance. By reducing circuit and power supply noise, and using a customized TCXO clock, Omnia SW-8 delivers accurate network signal that ensures stable music data transmission. The sound quality of a high-end audio system with a connected ethernet cable is also slightly improved when we reduce ethernet signal noise.

Features

  • Eight AUDIO GRADE 100 / 1000 Base-T Gigabit Ethernet Ports
  • Superior main clock accuracy
  • Customized Silent Angel Noise Absorber (SANA)
  • Two noise isolator for main power circuit
  • Two noise isolator for clock generator circuit
  • Medical Grade power adaptor

  • Interface: 8 x Audio Grade 100 / 1000 Base-T
  • LED
    • 1 x Power LED (Green)
    • 1 x Alarm LED (Red)
    • 8 x Port Status LEDs (Link / Activity)
  • Main Clock Accuracy: 0.1 ppm at 25 °C
  • EMI Absorber: Silent Angel Noise Absorber (SANA)
  • Noise Isolator
    • Main Power Circuit: 17.78 dB @ 100MHz x2
    • Clock Gen. Circuit: 20.79 dB @ 100MHz x2
  • Medical Grade Power Supply
  • Aluminum case
  • External Power: 5VDC at 1A Max. 5W. The power adaptor meets 2 X MOPP isolation regulation, which is highest level in medical grade, and has ultra low leakage current (<100μA)
  • Product Dimension: 154.5mm x 85mm x 26mm
  • Weight: 1.2 Kg (Gross Weight)
  • Temperature
    • Operating 0 ~ 35 °C
    • Storage -20 ~ 70 °C
  • Humidity
    • Operating: 10% ~ 90% RH (non-condensing)
    • Storage: 5% ~ 95% RH (non-condensing)

Be the first to Write a Review for this item!
