Novafidelity HA500H DAC & Headphone Amplifier
Zoom  Zoom
Novafidelity HA500H DAC & Headphone AmplifierNovafidelity HA500H DAC & Headphone AmplifierNovafidelity HA500H DAC & Headphone Amplifier
Novafidelity HA500H DAC & Headphone AmplifierNovafidelity HA500H DAC & Headphone AmplifierNovafidelity HA500H DAC & Headphone Amplifier

Novafidelity HA500H DAC & Headphone Amplifier

£2,199.00
£1,832.50 Exc. VAT |


|
Finish:

Novafidelity HA500H DAC & Headphone Amplifier

The HA500H is Novafidelity’s first dedicated hybrid headphone amplifier packed with an array of unique and versatile features. Powered by ECC82 as well as transistor op amps, the HA500H can be operated in both valve and solid-state mode depending on the listener’s preference or the type of musical material being enjoyed.

The HA500H features a unique dual Sabre DAC configuration making it capable of achieving a greatly increased dynamic range as well as a jump in sound quality.

To support as many headphone models as possible, the HA500H comes equipped with a high/low impedance switch. This caters for a wide range of source and headphone models and can easily power and support any headphone rated from 16 all the way up to 600 ohms.

Keeping up with wireless trends, Bluetooth A2DP and AVRCP profiles are supported along with  SBC (Subbabd codec), aptX, AAC and MP3 formats.

Main Features

  • ECC82 vacuum tubes
  • CNC machined aluminum chassis
  • Sabre ES9018K2M DAC chips
  • 5 function keys
  • 5” TFT LCD Display (800x480 pixels)
  • Bluetooth AVRCP / A2DP
  • Digital Sample rate up to 192 kHz
  • 12V trigger output and input
  • Support for 16 - 600 ohm headphone impedance
  • Coaxial, Toslink, AES / EBU digital inputs

Balanced Performance

Frequency response:
10 Hz ~ 80 kHz ± 0.5dB
THD + N @ 1KHz:
0.001% (-100 dB) 20 Hz ~ 20 kHz
Dynamic Range:
130 dB (Max 4 Vrms / 8 Vrms, Stereo)
Input Impedance:
47K Ohm, Standard 4Vrms (Adjustable from 2-8 Vrms)
Nominal output level (high / low):
High - 8 Vrms / Low - 4 Vrms
Frequency response:
10 Hz ~ 80 kHz: +/- 0.1 dB
Signal-to-noise ratio:
<-111 dB
Recommended headphone impedance:
16 ohms ~ 600 ohms

Unbalanced Performance

Dynamic Range:
130 dB (Max 2 Vrms / 4 Vrms, Stereo)
Input Impedance:
47K Ohm, Standard 2 Vrms (Adjustable from 1-4 Vrms)
Nominal output level:
High - 4 Vrms / Low - 2 Vrms
Frequency response:
10 Hz ~ 80 kHz: +/- 0.1 dB
Signal-to-noise ratio:
<-106 dB
Recommended headphone impedance:
16 ohms ~ 600 ohms

I/O

Symmetrical (XLR-4pin):
1: L +, 2: L-, 3: R +, 4: R-, Shielding: grounding
Unbalanced (6.35mm):
Tip: L, ring: R, shaft: ground

Power

Voltage:
AC 110-120 V ~ / 220-240 V ~, 50/60 Hz automatic switching

Physical Properties

Weight:
6.9kg
Dimensions (no feet):
270 x 333 x 85mm
Dimensions with feet:
270 x 333 x 90mm

Be the first to Write a Review for this item!
