Goldring Ethos Moving Coil Cartridge
Zoom  Zoom
 Goldring Ethos Moving Coil CartridgeGoldring Ethos Moving Coil Cartridge

Goldring Ethos Moving Coil Cartridge

  (4 Reviews)
£999.00
£832.50 Exc. VAT |  |

Goldring Ethos Moving Coil Cartridge

To ensure a cartridge reproduces an accurate transcription of the record groove, the cartridge components must be rigidly mounted to the tonearm, whilst simultaneously allowing the tiniest movements of the diamond stylus to be transmitted, via the cantilever, to the sensing coils. The Legacy boasts an ultra-low resonance magnesium metal body which is both very light and extremely strong.

For convenience and rigidity, it has threaded inserts allowing the cartridge to be easily mounted and accurately aligned into the headshell. The stylus is a very low mass 'Vital' fine line diamond, which is highly polished and gives extremely low distortion. To maintain rigidity, this is attached to a hard alloy cantilever which transfers the maximum level of detail from the diamond to the coils; the latter are hand wound using only the highest purity copper. To achieve the optimum compliance required to deliver a smooth, extended frequency response, the stylus damper is formed from a bespoke rubber mixture. Lastly, a precision, rare earth, Neodymium iron boron magnet helps deliver outstanding dynamics.

Line-Contact Stylus

The line-contact diamond profile provides a large contact area with the groove wall, improving the retrieval of high-frequency detail and reducing groove wear. Its vital-shaped shank has a low tip mass giving the design exceptionally good trackability.

Alloy Cantilever

The stiff and lightweight alloy cantilever tube has been tuned to the ideal length for cartridge stability and ride height. Its length has been optimised to reduce inertia in the suspension system and improve trackability.

Cross-Shaped Armature

The coils are wound around a cross-shaped armature of pure, high-permeability, Swedish iron. The reduced unsprung mass improves the ability for the stylus to track the groove wall and minimises cross-talk, improving the stereo image.

Optimised Suspension

The new damper pad uses a bespoke butyl rubber compound to keep the system critically damped. Combined with an expertly tensioned tie-wire, the cartridge remains ultra-stable even during the loudest and most complex passages.

Neodymium Magnet

A very light and powerful neodymium magnet is clamped between two pole shoes creating a perfectly uniform magnetic field gap, within which the cross armature is suspended. This gives Ethos its typically flat and extended frequency response.

Aluminium Body Shell

The body is precision-milled from a low density, rigid, aircraft grade aluminium which helps to maintain a low effective mass and enables it to dissipate unwanted resonances into the tonearm where they are effectively ‘grounded’.

Construction

  • Stylus profile: Vital line-contact
  • Stylus radius: 8 x 35 μm (0.3 x 1.4 mil)
  • Cantilever: Aluminium alloy
  • Coil wire: Oxygen free copper
  • Coil windings: 32 per channel
  • Armature type: Low mass cross shape
  • Magnet: Neodymium
  • Generator model: GOL-1
  • Body material: Aircraft aluminium
  • Replacement stylus: Factory replaceable

Transducer Characteristics

  • Frequency range: 10 Hz - 32 kHz
  • Frequency response: ± 2 dB (35 Hz - 20 kHz)
  • Channel balance: <1 dB at 1 kHz
  • Channel separation: >30 dB at 1 kHz
  • Sensitivity: 0.5 mV ± 1 dB @ 1 kHz, 5 cm/s (rms)
  • Static compliance: 25 mm/N
  • Dynamic compliance: 15 mm/N
  • Vertical tracking angle: 20°

Model Details

  • Name: Ethos
  • Product code: GL0003M
  • Colour: Silver
  • Cartridge type: Moving coil

Electrical Characteristics

  • Load resistance: 100 Ω
  • Load capacitance: 100 - 1000 pF
  • Internal inductance: 7.5 μH typical
  • Internal resistance: 4 Ω typical

Mechanical Characteristics

  • Cartridge mass: 7.7 g
  • Total mass (incl. fixings): 8.5 g
  • Fixing centres: 12.7 mm (0.5 in)
  • Playing weight: 1.5 - 2.0 g (1.75 g)
Average Rating (4 Reviews):
Write a Review and share your opinions!

Rating:
Best Buy
19 February 2024  |

At this price point a no brainer. Tech specs perfect, Not as emotional as the Goldring Elite but much better build quality and much more resolving.

Was this helpful to you?  Yes  /  No

This review has not been appraised.


Rating:
Goldring Ethos -seems to hit all the right notes
11 December 2023  |

Recently purchased the Goldring Ethos to replace my dear AudioTechnica ART-9, that was giving me rumble problems due to mass-compliance poor compatibility with my tone arm.
I shopped for the Ethos based on mass, compliance, and reviews. Several things are striking about this product, in particular that it is the top item of a company that has been producing quality cartridges for more than a century. Due to its geometry, this cartridge requires very careful alignment, and it seems it will take perhaps more than 200 hours to really sing and settle on my system, so this is a long term purchase, an item that will fully bloom with time and patience. I look forward to the next many years with this cartridge !

Was this helpful to you?  Yes  /  No

This review has not been appraised.


Rating:
Very even and detail
17 March 2022  |

After a month of usage, I found Ethos very even, covering across the audio range without feeling that it is great with this but bad at that etc. It is detail without being edged analytic. It is also very slightly warm like reviews said. Over all very dependable and competent, especially given its price.

Was this helpful to you?  Yes  /  No

4 of 4 people found this review helpful.


Rating:
Outstanding cartridge
14 June 2020  |

The Goldring Ethos is a delight. The threaded body and straight sides make it easy to fit and align. It sounds sublime on my Planar 8 - surface/groove noise are minimal, distortion Is absent, tone is just a shade warm, detail retrieval is excellent, and midrange and vocals are breathtaking. Highly recommended.

Was this helpful to you?  Yes  /  No

30 of 31 people found this review helpful.
