Benz Micro ACE SH High Output Moving Coil Cartridge
Zoom  Zoom

Benz Micro ACE SH High Output Moving Coil Cartridge

£795.00
£662.50 Exc. VAT |  |

Benz Micro ACE SH High Output MC Cartridge

  • 2.5mV Output

The Benz ACE is one of our favorite budget phono cartridges. Based on the generator system and stylus assembly of the Benz Glider with a protective acrylic body, the ACE is a handmade cartridge, one of the only hand-built cartridges at this price point! This is a true music lover's cartridge, warm and natural through the mid-range, with great bottom-end extension and silky smooth high frequencies. If you just want to play record after record with a big smile on your face...the ACE is the cartridge for you! The Benz ACE is simple to install and is available in three different outputs to match any phono-stage.

Specifications:

  • Output Voltage: 2.5mV
  • Cantilever: Solid Boron, 0.28mm
  • Stylus: Nude line-contact diamond, mirror polished
  • Stylus tip radius: 6x40 um
  • VTA: 20 degrees
  • Coil: Pure Iron Cross
  • Weight: 8.8 grams
  • Internal Impedance: 12ohms
  • Frequency Response: 20-20,000 Hz
  • Channel Balance: Better than 0.5db
  • Channel Separation: Better than 35db at 1kHz
  • Tracking force: 1.8-2 grams
  • Recommended loading: 200-47,000 ohms
  • Break-in period: 40 hours
  • 2 Year Warranty
