FREQUENCY RESPONSE (+/- 3 dB) 38Hz – 20kHz
SENSITIVITY1 99dB @ 2.83V / 1m
POWER HANDLING (CONT/PEAK) 100W / 400W
MAXIMUM SPL 116dB Continuous
NOMINAL IMPEDANCE 8 ohms Compatible
CROSSOVER FREQUENCY HF: 5.2kHz
MF: 650Hz
HIGH FREQUENCY DRIVER K-100-TI 1” (2.54cm) Titanium diaphragm
compression driver on a K-79T horn
MIDRANGE K-702 1.75” (4.45cm) Polyimide Compression
Driver mated to a K-703-M horn
LOW FREQUENCY DRIVER K-281 12” (30.48cm) Fiber-composite cone
woofer, KD-15 15” (38.1cm) Passive cone radiator
ENCLOSURE MATERIAL 3/4” MDF
INPUTS Dual binding posts / bi-wire / bi-amp
HEIGHT 35.75” (90.81cm)
WIDTH 16.63” (42.24cm)
DEPTH 13” (33cm)
WEIGHT 72 lbs (32.7kg)
