Main Bearing Spindle
Grade 303 Stainless Steel
Main Bearing Housing
Brass
Platter
High Mass 10mm Glass Platter with Anodised Aluminium edge
Structure
Isolated Single plinth Design
Isolation
1-level decoupling
Motor
Vibration Isolated
24 Pole Synchronous
Speed Controller
Built in High precision digitally Synthesised AC signal generator with high current low distortion output
Speed
33 RPM & 45 RPM (Switchable)
Dimensions (Including Lid (W x H x D))
432 x 115 x 353 mm
Dimensions (Excluding Lid (W x H x D))
432 x 104.5 x 353 mm
Phono Stage
Built in MM phono stage
Phono Stage Bypass
Yes, with switch for external phono stage.
Phono Stage Gain (active)
42dB @ 1kHz
Phono Stage Signal to Noise (active)
>64dB
Phono Stage Impedance (active)
47k / 100pF
Output
Stereo RCA with provided low capacitance phono cable
Power
5V 1.5A external SMPS
Arm Material
5052 Aluminium top with ABS bottom section
Recommended Tracking Force
1.8 - 2.2 g
Internal Wiring
0.08OFC copper wire
