Matrix Audio Element X2 Streamer

The evolution of elements

The element series music streamer, which represents the new design concept of Matrix Audio, is facing an update after they were announced three years ago. The element X2 will be a new start, it acts as a full-featured stand-alone source device for your audio system, and also brings your existing traditional two-channel system into the world of high-res streaming audio. Simplify your audio system and enjoy the music.

Perfect all-in-one solution

element X2 music streamer is a multi-functional audio source that can play local music files or online streaming audio. It has a built-in preamplifier and headphone amplifier, which can drive various of headphones directly, or connect to power amplifiers or active speakers easily. Besides of rich digital input ports, the element X2 even has a pair of analog input ports which allows you to connect vinyl turtables or CD players to it. The HDMI ARC input helps you get a better sound quality when watching TV. Roon Ready, UPnP and AirPlay are not absent as well. Excellent human-computer interaction, with the MA Remote app by Matrix Audio, you can easily configure your devices, browse and playback music files. For audiophiles looking for an all-in-one solution which has superior resolution and presents all the details perfectly, element X2 might be your best choice.

New UI New impression

The 2nd gen element series music streamer is equipped with a 3.46 inch LCD touch screen. When playing over the network, or playing local music via MA player, rich information of the track is displayed on the screen. The touch screen allows you to perform various operations more conveniently. The newly added playback touch keys make the new generation of element music streamers easier to use.

Richer than rich

If you own a big treasure of digital audio, MA player allows you to easily browse and play music in USB drives or NAS. If you prefer high-res online streaming, TIDAL, Qobuz, Spotify and Internet radio will be your huge library of music. Roon Ready, DLNA/UPnP and AirPlay 2 bring you different music streaming experiences.

Hardware Platform
- CPU: NXP i.MX 6Quad 4x Cortex-A9 @1.2 GHz
- D/A Chip: ES9038PRO
- Clock Source: Crystek CCHD-950
Digital Input
- Coaxial & Optical
- PCM 16-24 Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
- DSD 2.8MHz (DoP)
- IIS LVDS
- PCM 16-32 Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz
- DSD 2.8MHz, 5.6MHz, 11.2MHz (DoP)
- DSD 2.8MHz, 5.6 MHz, 11.2 MHz, 22.4MHz (Native)
USB Audio
- PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz
- MQA 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz MQA or MQA Studio stream
- DSD 2.8MHz, 5.6MHz, 11.2MHz (DoP)
AUX Input
- RCA
- SNR: >-106dB A-weighting
- THD+N: <0.0025%@1k, <0.0030%@20Hz-20kHz
- Frequency Response: 20Hz-20kHz ±0.07 -3dB@43kHz
- Channel Crosstalk: >-102dB
- Input Level: 2.1VRMS Maximum
Line Output
- XLR
- SNR: >-131dB A-weighting
- THD+N:<0.00012%@1k, <0.00020%@20Hz-20kHz
- Frequency Response: 20Hz-20kHz ±0.05 -3dB@85kHz
- Crosstalk: >-146dB
- Output Level: 4.5VRMS@0dB,15.8VRMS@+10dB
RCA
- SNR: >-125dB A-weighting
- THD+N:<0.00012%@1k, <0.00020%@20Hz-20kHz
- Frequency Response: 20Hz-20kHz ±0.05 -3dB@85kHz
- Channel Crosstalk: >-137dB
Headphone Output
- 4.4 mm balanced
- SNR: >-119dB A-weighting
- THD+N:<0.00055%@20Hz-20kHz 4VRMS
- Frequency Response: 20Hz-20kHz ±0.1 -3dB@85kHz
- Output Impedance:<12O
- Output Power: 2600 mW@33O, 1100 mW@300O, 580 mW@600O, 1%THD
- Gain: +18dB@Low Gain, +28dB@High Gain
- 6.35 mm unbalanced
- SNR: >-116dB A-weighting
- THD+N:<0.00055%@20Hz-20kHz 2VRMS
Frequency Response: 20Hz-20kHz ±0.1 -3dB@85kHz
- Output Impedance:<6O
- Output Power: 1600mW@33O, 290 mW@300O, 150mW@600O, 1%THD
- Gain: +18dB@Low Gain, +28dB@High Gain
Network
- LAN: 10/100/1000 Mbps
- WLAN: 2.4 GHz / 5 GHz
USB
- The USB port provides a maximum power of 5V/1A.
- The USB port works with devices which conform to the USB mass storage standard and supports FAT, FAT32, exFAT, and NTFS file formats, but is not guaranteed to be compatible with all storage devices.
- Trigger
- Trigger in: DC 6-12V<10mA
- Trigger out: DC 12V/50mA MAX
- MA player
- Controller app: MA Remote App
Local Playback
Format Supported:
- MP3 , WMA , WAV , AIF, AIFC, AIFF, AAC, FLAC, OGG, APE, ALAC, M4A, DSF, DFF, CUE
PCM Sampling Rate:
- PCM 16-24Bit 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz
- MQA 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz MQA or MQA Studio stream
- DSD Sampling Rate:
- DSD 2.8MHz, 5.6MHz, 11.2MHz, 22.4MHz
Roon Ready
PCM Sampling Rate:
- PCM 16-24 Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz
- MQA 16-24 Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz MQA or MQA Studio stream
- DSD Sampling Rate:
- DSD 2.8MHz, 5.6MHz, 11.2MHz, 22.4MHz
The audio specs depend on the service provider
- AirPlay 2
- DLNA/UPnP
- TIDAL Connect
- Spotify Connect
- vTuner
Power Specs
- Power Voltage: AC 100V-120V 50/60Hz / AC 220V-240V 50/60Hz
- Standby Power Consumption < 5W
- Maximum Power Consumption < 50W
Weight & Size
- Weight: 4 kg (8.82 pounds)
- Size: Width: 340 mm (13.39 inches), Depth: 259 mm (10.20 inches), Height: 58 mm (2.28 inches)
Accessory
- RM4 remote control
- Power cable
- Quick start guide
- Warranty card
