Specifications are subject to change without notice.

• STREAMING PROTOCOL:

  • UPnP AV protocol with audio streaming extension
  • Gapless Playback
  • On-Device Playlist

• SUPPORTED AUDIO FILE FORMATS:

  • DSD LOSSLESS:

    • DSF (DSD), DIFF (DSD), DoP (DSD)

  • PCM LOSSLESS:

    • FLAC, Apple Lossless (ALAC), WAV, AIFF

  • COMPRESSED (LOSSY) AUDIO:

    • MP3, AAC (in M4A container)

• SUPPORTED AUDIO SAMPLE RATES, BIT DEPTHS, NUMBER OF CHANNELS:

  • PCM, 44.1kHz - 384kHz, 16 - 32bit, Stereo
  • DSD, 2.8MHz, 1bit, Stereo (5.6MHz on LUMIN S1)

• UPSAMPLING RATES & BIT DEPTHS:

  • DSD upsampling option for all files up to 96kHz

• SUPPORTED CONTROL DEVICES:

  • All models of Apple iPad (v2 or later). iOS 5.0 or later required. Full Retina Display support.

• APP FEATURES:

  • High-resolution artwork. Artwork caching. AirPlay compatibility. Multiple-tag handling. ‘Composer’ tag support. Find & Filter. Tag browsing.

• INPUT:

  • Ethernet network 100Base-T
  • USB storage, flash drive, USB hard disk (Single-partition FAT32, NTFS and EXT2/3 only)

• OUTPUTS:

  • ANALOG AUDIO:

    • XLR balanced, 4Vrms, pin 2 Hot
    • RCA unbalanced, 2Vrms

  • DIGITAL AUDIO:

    • BNC SPDIF:

      • PCM 44.1kHz–192kHz, 16–24bit
      • DSD (DoP, DSD over PCM) 2.8MHz, 1bit

• FINISH:

  • Raw brushed aluminium
  • Black anodised aluminium finish is available as a special order item. Please contact your retailer for costs and lead time

• OTHER:

  • Firmware-upgradable for further features and enhancements
