Standard Top plate (Width, Depth) 130mm (5.11”) x 170mm (6.69”)
Base Plate (Width, Depth) 260mm (10.2”) x 365mm (14.37”)
Overall height 620mm (24.4”) (inclusive of floor spikes)
Weight capacity (per stand) 30kg (66.12 lbs)
Approximate maximum Atabite mass loading filler capacity (620mm high version) is 42.5kg (93.6 lbs) per pair.
Optional (Purchase separately)
**Top plate pack dimensions (Width/Depth)
160mm x 220mm (6.29” x 8.66”)
140mm x 210mm (5.5” x 8.26”)
190mm x 305mm (7.48” x 12”)
Spike shoes- 2 x packs of Atacama HD-L spike shoes are recommended if the stands are being placed on a delicate floor covering.
Mass Loading Plate pack- This pack is compatible with NeXXus Series.
Gel Pads- NeXXus Pro Studio Specification come with the new High Load trapezoidal gel pads.
Atabite Mass loading filler- For NeXXus 600 Enthusiast, three to four 7kg tubs of Atabites per pair of stands will be sufficient for most applications. The exact amount to use is room, system, and personal choice dependent. See Atabite product listing for more details.
*Note- The 130mm x 170mm top plate pack is included with Nexxus speaker stands as standard. If you have selected one of the upgraded top plate packs, we suggest that the unused top plates be repurposed by attached them to the underneath of the base plates via the tube fastening bolts. This will increase the low-down mass of the stands, reduce base plate resonance, increased rigidity and will avoid the original top plates being misplaced should they be required later.
**The 180mm x 150mm Optional top plate pack is not suitable for NeXXus Pro Studio as the overall combined depth of the twin vertical tubes is deeper than the top plate.
Atacama NeXXus series speaker stands are designed and manufactured in the UK.
