Esoteric Grandioso S05 Stereo Power Amplifier
Zoom  Zoom
 Esoteric Grandioso S05 Stereo Power AmplifierEsoteric Grandioso S05 Stereo Power Amplifier

Esoteric Grandioso S05 Stereo Power Amplifier

Price to follow shortly

Call for price
£0.00 Exc. VAT |


|


Esoteric Grandioso S05 Stereo Power Amplifier

Welcome to first class.

This sleek system, consisting of the N-05XD and the S-05 is simple, yet versatile. All you have to do is carefully choosea pair of speakers, and you will be set for life..

The new S-05 – a class-A power amplifier thoroughly focused on delivering all of music’s unique tonal qualities from a more compact stereo configuration, embracing the philosophy of the Grandioso M1X:

“minimal circuitry – maximum output”.

Key Features

Lavish material employment borrowed from the M1X, and simple and straight circuit design concept

Dual monaural construction

Esoteric’s proprietary current signal transmission, “ES-Link Analog” Input

Bi-polar 3 Parallel Push/Pull

940VA Large EI-core power transformer

Esoteric custom capacitors (10,000μF × 4/ch)

Balanced input amplifier

BTL / Bi-amp mode switch for dual amplifier configuration
BTL: 60W/ch (8Ω, Class-A), 120W/ch (4Ω)

Key Specifications

Rated Output Power: 30W + 30W (8Ω, Class-A), 60W + 60W (4Ω)

Analog Inputs: ES-Link Analog × 1 pair, XLR × 1 pair, RCA × 1 pair

Overall Dimensions: 445 × 191 × 444mm (W×H×D, including protrusions)



Audio performance

1000
Frequency response 5Hz to 100kHz (+0dB, –3dB, 8Ω)
S/N ratio 115dB (IHF-A)
Total harmonic distortion 0.003% (1kHz, 8Ω, 150W)
Gain 29dB
Damping factor
Speaker Output
Rated ouput power 150W + 150W (8Ω)
300W + 300W (4Ω)
Maximum output power 600W + 600W (2Ω)
Analog audio inputs
XLR 1 pair
RCA 1 pair
General
Power supply
  AC 230V, 50Hz
  AC 120V, 60Hz
  AC 220V, 60Hz
Power consumption
AC 230V model 430W (no signal: 150W)
AC 120V model 430W (no sginal: 150W)
External dimensions (W×H×D) 445 × 221.5 × 497.8mm
17-⅝" × 8-¾" × 19-⅝" (including protrusions)
Weight 47kg / 103-⅝ lb
Included accessories Power cord × 1
Felt pads × 4
Power cord support bracket × 1
Power cord support bracket screw × 2
Owner's manual × 1
Warranty card × 1
