Arcam HDA SA30 Integrated Amplifier
Zoom  Zoom
 Arcam HDA SA30 Integrated AmplifierArcam HDA SA30 Integrated Amplifier

Arcam HDA SA30 Integrated Amplifier

£1,999.00
£1,665.83 Exc. VAT |


|

PRE ORDER NOW FOR AUTUMN DELIVERY.



Arcam SA30 Integrated Amplifier

The new Arcam SA30 integrated amplifier sports 120 watts of Class G amplification for impeccable sound, control and efficiency.

This latest product from the HDA range has the same new sleek fascia and casework as the rest of the HDA range and houses an extensive feature list. Firstly, there is a dedicated switchable MM/MC phono input befitting a high end performance amplifier. The SA30 also comes supplied with 4x digital inputs (2x co-axial and 2x S/PDIF), plenty to connect all those digital audio devices. The SA30 is equipped with the ESS Sabre ESS9038 32-bit high-end DAC. There are 4x analogue inputs are available for legacy connectivity and even a HDMI ARC enabled input is on hand. There’s also a comprehensive I/P control suite, including Control4 and Crestron compatibility.

Devotees of the latest high resolution digital audio systems will welcome the SA30’s support for MQA as offered by the likes of TIDAL Masters. The SA30 is also ROON ready and its ROON end point status means that it is all set to receive audio from ROON’s digital music player and library system.

Finally, the SA30 comes with full Dirac Live room correction (3 profiles available) to ensure the best possible sonic results.



What is Class G?

There are two frequent problems with hi-fi amplifiers. Class A, the traditional audiophile’s choice, uses a single power supply constantly running at full capacity, even when there’s no signal coming through. Great for reproducing those subtle details at low levels however struggles to provide extreme power when needed.

Class A/B, the most common amp class, switches between the two internal amplifiers, one for each half of the waveform. Far more efficient but often a recipe for crossover distortion, since those low-level details we crave can get lost within any mis-match between the two switching over.

Class G is essentially a hybrid amplifier, utilising Class A specifically for low-level signals, but when required switching in an additional power supply to power those larger sections of the waveform.







120W of power per channel into 8 Ohms, 220W into 4 Ohms
 5 analogue inputs including switchable MM/MC PHONO
 4 digital inputs
 1 ARC input
 GoogleCast, Airplay 2, uPnP Streamer
Roon endpoint
 Full I/P control including Control4 and Crestron
3 Dirac EQ profiles (input assignable)



Power Output Both Channels Driven 120W Into 8Ω, 220W Into 4Ω
Frequency Response 20Hz – 20kHz ± 1dB
Total Harmonic Distortion + Noise 0.002%
Nominal Sensitivity 1V
Input Impedance 10kΩ
Signal/Noise Ratio (A-wtd) 50W, ref. 1V Input 120dB
DAC 32-bit Sabre ESS9038K2M
Mains Voltage 110-120V or 220-240V, 50-60Hz
Maximum Power Consumption 800W
Dimensions W x H x D 433mm x 100mm x 323mm
Weight 12 Kg
Packaged Weight 14 Kg

Be the first to Write a Review for this item!
