The New M2 CD Player benefited immensely from the development of the new upcoming Platinum CD player The M2 utilises a one piece optimised mother board, de-coupled mechanism and dedicated transformer/power supplies for the analogue filters and the outputs.
The dynamic resolution of the M2 CD player handles the loudest to quietest musical passages with flare and ease making any genre of music a joy to listen to. The resolution of detail is like being within a ‘musical envelope’ bringing an almost analogue feel to the whole experience; a perfect match to the astonishing M2 Integrated amplifier.
De-coupled laser mechanism, super precision master clock combined with its 12 independent and fully regulated digital & analogue circuits create a seam less harmonic musical experience that is second to none.“Combines refinement, bite and rhythmic ability better than anything else we have heard at this price... ”
Operating System
CD digital audio system (CD, CD-R, CD-RW)
Frequency Response
20Hz – 20kHz ± 0.2dB
Harmonic Distortion
< 0.0015% @ 0dB, 1kHz (Typically 0.0005%) < 0.005% @ -30dB, 1kHz < 0.01% @ 0dB, 20kHz
Intermodulation Distortion
< 0.001% @ 0dB (Typically 0.0005%)
S/N Ratio (IHF-A Wtd.)
105 dB
Wow & Flutter
Quartz precision
Channel Separation
>100 dB @ 1kHz >100 dB @ 20kHz
Output Voltage
1.95Vrms
Analogue Outputs
L&R, RCA Gold plated L&R Balanced XLR Gold plated
Digital Outputs
75 Ohm Coaxial, RCA Gold plated 110 Ohm Balanced AES/EBU, XLR Gold plated Optical, Toslink
D/A Conversion
PCM1798 Advace Segment, Audio-Stereo DAC
Resolution/Sampling
24 bits / 192 kHz
Oscillation
3rd Overtone Oscillation
Crystal
Super precision, custom made
Mechanical Isolation
Main chassis de-coupling feet, custom made Laser mechanism 2 stage de-coupling
Jitter
<130 psec (Typically <70 psec)
Idle Pattern
<-105 dB
Stop band Rejection
<-95 dB
Power Supply
x2 high performance low noise toroidal transformers 12 fully regulated power rails
Power Source
100V – 120V 50Hz / 60Hz 220V – 240V 50Hz / 60Hz
Power Consumption
< 20 W
Dimension
432 x 330 x 70 (W x D x H) mm 432 x 330 x 80 (including feet)
Weight
10Kg
