Cardas Frequency Sweep and Burn-In Record
Zoom  Zoom

Cardas Frequency Sweep and Burn-In Record

  (2 Reviews)
£49.95
£41.63 Exc. VAT |  |



Cardas Frequency Sweep and Burn-in Record

The Cardas Frequency Sweep and Burn-in Record is a unique tuning tool for system set-up, diagnostics and maintenance. It was produced by George Cardas and mastered by Stan Ricker. The "Sweeper", in addition to the standard tones, includes frequency sweeps that ultrasonically clean the cartridge stylus and degauss the entire system, locked, pink noise grooves that repeat endlessly, blank plateaus, a sync label to check platter speed. All on a 180 gram pressing with a smiling Stan cover.





Side 1 • Sweeper • 45 rpm. Note: This are three cuts, interleaved with smooth sections, to be played at 45 rpm. Also works at 33 1/3rd rpm.

Track 1. Short Sweeps, short version (52 seconds)

Lock-out

Track 2. Short Sweeps, long version (4 minutes 46 seconds)

Lock-out

Track 3. “I’ve Got a Feeling I’m Falling” Artists: Tom Loncaric Band. Music Thomas Waller and Harry Link. Publisher: Ann Rachel Music. (2 minutes 29 seconds)

Lock-out

Track 4. 1K tone (740.74Hz @ 33 1/3rd rpm)

Lead-out spiral and final tie-off



Side 2 • Burn-In • 33 1/3 rpm. Note: Burn-in is mastered at two different speeds and designed to be played at 33 1/3 rpm. The first section, from the outside edge to the lock-out groove (the stylus will stay in the groove until lifted out), is mastered at 16 2/3 rpm. Tracks 2, 3 and 4 are mastered at 22 1/2 rpm.

Track 1a. Voice announcement by George Cardas, "Greetings from the left channel"

Spiral

Track 1b. Voice announcement by George Cardas, "From the right channel"

Spiral

Track 1c. Voice announcement by George Cardas, "From both channels" Note: This is lateral modulation (mono, in phase).

Spiral

Track 1d. "In polarity" Both channels in positive polarity

Spiral

Track 1e. "Out of polarity" Both channels in reversed or negative polarity Spiral

Track 1f. 13 strikes on a high "B-flat" on a piano Note: The last of the 3 strings are brought into zero-beat, dead-on tuning. Listen for the impact of hammer on string, quickly followed by room reflections mingling with one another, followed by a keener sense of the piano sound itself, as the ring-out time of the string exceeds that of the reverb time of the room.

Spiral

Track 1g. Hollow sticks, of various lengths and diameters, being struck, one on another. Note: It is recorded in a very reverberant, spacious environment. The spatial, impact and directional cues will not sound correct if the polarity is wrong.

Lock-out. Note: The remainder of this side is cut at 22.5 rpm and consists of three wide bands of pink noise, separated by two blank, 1/2 inch wide plateaus. The plateaus are protected by two blank grooves on each side, to keep the stylus from sliding into the pink noise. The three wide bands are groups of individually locked grooves of mono pink noise, recorded at "0" dB, relative to NAB standard level. These are continuous grooves and the stylus will stay in a groove until it is lifted out. This 180 gram pressing is made of specially formulated hard vinyl.

Track 2. 20 locked grooves, lateral modulation (mono)

1/2” wide, unmodulated plateau

Track 3. 32 locked grooves, vertical modulation (out-of phase)

1/2” wide, unmodulated plateau

Track 4. 20 locked grooves, lateral modulation (mono)

Track 5. 26 unmodulated grooves Note: These unmodulated grooves facilitate electro-forming (matrix) operations and help vinyl flow in the record press, for a quieter, flatter disk.

Lead-out spiral and final tie-off

Pressing: 180 gram, specially formulated hard vinyl
Mastering Lathe: Neuman VMS 66 lathe
Cutter Head: Helium cooled, Neuman SX-74
Controller: A Sontec Compudisk computer
Motor: Technics 5-speed direct drive Console and cutter head electronics: Keith O. Johnson

Average Rating (2 Reviews):
Write a Review and share your opinions!

Rating:
Very useful.
03 April 2019  |

I don’t like using a brand new stylus on valuable vinyl, so use older records to start with, giving the needle and cantilever some time to bed in. When I learnt about the Cardas Burn-in record I bought one, and it’s very useful. It accelerates the wearing in process of the cartridge and stylus. I’ve not had time to use the other applications yet, so can’t comment on them. The record is good value for money, and the composition of the vinyl is hardened for frequent use.

Was this helpful to you?  Yes  /  No

1 of 2 people found this review helpful.


Rating:
Cardes Frequency Sweep Record
19 November 2013  |

Does what is says very easy to follow. But great way to check if turntable and speakers set up correctly.

Was this helpful to you?  Yes  /  No

2 of 2 people found this review helpful.
