Naim's audio experts have been working on the concept of a music server device capable of audiophile-quality replay for some years. It was only when we were satisfied that we could deliver true Naim performance from this format, that we felt happy to introduce such a product bearing the Naim logo. Our uncompromising standards and adherence to Naim's legendary engineering principles, once again, ensured we delivered a music player that was going to stand up to the exacting standards of our audiophile customers.
HDX-SSD has been developed to combine the convenience of a digital music device with the performance of a true Naim source component. As with all Naim products, the HDX-SSD's performance results from achieving the optimum balance of electronic and mechanical engineering.
Audiophile playback electronics: HDX-SSD playback begins with a unique Naim-designed, multiple power supply PCI interface that feeds the audio data to the digital-to-analogue conversion stage. The HDX-SSD's playback electronics borrow heavily from the established Naim practices that produce the world's finest sounding CD players. They incorporate multi-regulated power supplies, Burr-Brown digital-to-analogue converters, ultra-low jitter re-clocking, seven pole analogue output filtering, and every last thing we know about maximizing musical sound quality. Even an optional external XPS or 555 PS power supply can be connected for even greater musical performance.
Simple and bit-perfect CD ripping
Ripping CDs with an HDX-SSD could not be simpler. Open the CD drawer, insert the CD and in a few minutes you have a bit-perfect copy. You can make bit-perfect rips of up to 20,000 albums can be fully supported on your home network. The technology of ripping is anything but simple, however. To achieve its bit-perfect copy of the CD data the HDX-SSD employs some of the most advanced data reading and error analysis algorithms ever deployed in the pursuit of sound quality. They are unique to Naim, too.
Your music collection is automatically catalogued and in one place
Browsing your music collection with HDX-SSD is a breeze. No more peering at shelves of jewel cases and promising that they'll be in alphabetical order one day. Each CD ripped by the HDX-SSD is automatically catalogued through enquiry to an on-line database and its data added to the internal library.
Simplified music search and selection
Searching for music is not limited to albums and tracks. Want to search by composer, performer, artist, or orchestra? Go ahead. Can't remember the name of the Chris Squire album you ripped that Mel Collins played sax on? The Naim Extended Music database, with the power of AMG at its heart will find it for you. Remember the smallest detail and all your music is there at the touch of a screen. And by the way, the Chris Squire album was Fish Out Of Water.
Controllable from your PC
With an HDX-SSD connected to a home network you don't have to be in the same room to browse your music library. The Naim Desktop Client is a Windows PC application that can control your HDX-SSD, browse its music files and handle player setup and maintenance easily and intuitively.
A choice of user interfaces
The HDX-SSD incorporates a front panel touch screen that offers all the control you'll need. But perhaps you fancy controlling the HDX-SSD from the listening position? Well, connect a small display screen, or even your television, and you can operate the HDX-SSD with its remote handset. Or perhaps you want to run the HDX-SSD wirelessly from your laptop? Easy; use either the Desktop Client application or a web browser. There's a USB touch-screen option too. You can also use an iPhone or iPod Touch.
IP-enabled for multi-room replay
The HDX-SSD can provide up to six different streams of music simultaneously over a home network. Install an HDX-SSD and you've installed the heart of a multi-room audio system too. To find out more about Naim's multi-room system NaimNet, visit www.naimnet.com.
Design features overview
- Independent and separately grounded multi-regulated power supplies for analogue and digital stages.
- Burr-Brown PCM1791A digital to analogue converter
- Naim-designed PCI audio and drivers with ultra-low jitter clocks
- A seven-pole analogue output filtering using Burr Brown OPA604 op amps
- Custom designed monolithic air core transformer isolated analogue output stages
- Separate toroidal transformer and linear power supply for audio circuits Electrical isolation of data lines and clocks
- Ultra low noise triple-regulated power supplies
- Naim reference non-magnetic, low-resonance low microphony case
Hi-Fi News - December 2009 - "When it came to the interplay of drums and bass the HDX was in a class of its own"
Record Collector - June 2009 -"It competes with more expensive CD players and is not a frivolous 'lifestyle' product - this is a serious music machine"
Hi-Fi World - November 2008 -"If there was ever a high end computer audio 'crossover' product, this is it"
Gramophone - October 2008 -"the best part of this machine is the sound; its one of the best CD players I've ever heard"
Hi-Fi Choice - October 2008 -"In addition to modern convenience features, the HDX is a no-holds-barred example of Naim's traditional 'God is in the detail' audiophilia."
- What Hi-Fi? Sound & Vision - July 2008 -"It works with its own drives, USB devices or Network attached Storage, and the Naim Extended Music Database can handle up to 20,000 CDs-worth of data."
- 16GB Single Level Cell (SLC) Enterprise Drive
- Bit-perfect CD ripping to external network attached storage (NAS)
- Naim Extended Music Database - supports extended metadata to track-level resolution for intuitive browsing & selection
- Naim Network Scanning - will discover all playable music & metadata available on networked computers (PC & Mac)
- Naim UPnP Server - will serve audio streams to any UPnP rendering playback device, such as the NaimUniti or UnitiQute
- Ethernet network connectivity for reliability
- Front-panel USB port for replay of USB memory stick-stored audio
- Multiple intuitive control interfaces: Front panel touch screen / TV / Web / Desktop Client and iPhone / iPod Touch app
- Naim Desktop Client - for browsing music files, player setup and maintenance with a PC
- WAV, MP3, AAC, FLAC, AIFF, Windows Media-formatted content files and ALAC files played from any USB-connected storage device
- Native 24 bit/192kHz playback and internal architecture with support for hi-resolution audio formats. Plays WAV up to 24bit/192kHz, MP3 both vbr and fbr, FLAC up to 24bit/192kHz, AAC (m4a only), AIFF, ALAC, OGG Vorbis and Windows Media-formatted content files.
- CD replay with display of cover art, album and track data
- Performance upgradeable with additional of external XPS or 555 PS power supply and DAC digital to analogue converter
- StreamNet-enabled for NaimNet audiophile multi-room replay of up to six streams over a home network
- Separate toroidal transformer and linear power supply for audio circuits
- Naim-designed PCI audio and drivers with ultra-low jitter clocks
- S/PDIF Digital output on BNC or TosLink
- Seven pole analogue output filtering
- Composite, S-Video or VGA display output for screen or touchscreen
- Electrical isolation of data lines and clocks
- Ultra low noise triple-regulated power supplies
- Naim reference non-magnetic, low-resonance low microphony case
- Quiet in operation
- British design and build
